Work Height         24’ 6” (7.47 m)

Raised Platform Height         18’ 6” (5.64 m)

Lowered Platform Height         41” (1.04 m)

Overall Width         32” (0.81 m)

Overall Length         71” (1.80 m)

Stowed Height (Rails Up)         84” (2.13 m)

Stowed Height (Rails Down)         79.75” (2.02 m)

Platform Width (Inside Dimension)         26” (0.66 m)

Platform Length (Inside Dimension)         61” (1.55 m)

Extension Deck (Roll Out)         3’ (0.91 m)

Ground Clearance (Stowed)         3.5” (8.9 cm)

Ground Clearance (raised)         0.50” (1.3 cm)

Wheelbase         54” (1.37 m)

Weight         3,255 lbs (1,476 kg)

Gradeability         25%

Turning Radius (Inside)         0

Turning Radius (Outside)         65” (1.65 m)

Lift Time (With Rated Load)         19 sec

Lower Time (With Rated Load)         25 sec

Drive Speed (Stowed)         2.1 mph (3.4 km/h)

Drive Speed (Raised)         0.7 mph (1.1 km/h)

Maximum Drive Height         Full Height

Capacity         500 lbs (227 kg)

Distributed Capacity (Main Platform)         250 lbs (113 kg)

Distributed Capacity (Extension Deck)         250 lbs (113 kg)

Local Floor Load (With Rated Load)         168 psi (1,159 kPa)

Overall Floor Load (With Rated Load)         243 psf (1,188 kg/m2)
