Work Height         31' 7" (9.63 m)

Raised Platform Height         25’ 7” (7.79 m)

Lowered Platform Height         46” (1.17 m)

Overall Width         32” (0.81 m)

Overall Length         91.6” (2.32 m)

Stowed Height (Rails Up)         90” (2.29 m)

Stowed Height (Rails Down)         76” (1.93 m)

Platform Width (Inside Dimension)         28” (0.71 m)

Platform Length (Inside Dimension)         83” (2.11 m)

Extension Deck (Roll Out)         3’ (0.91 m)

Wheelbase         69” (1.75 m)

Weight         4,190 lbs (1,900 kg)

Gradeability         25%

Turning Radius (Inside)         43” (1.09 m)

Turning Radius (Outside)         104” (2.64 m)

Lift Time (With Rated Load)         47 sec

Lower Time (With Rated Load)         41 sec

Drive Speed (Stowed)         2.4 mph (3.9 km/h)

Drive Speed (Raised)         0.6 mph (1.0 km/h)

Maximum Drive Height         Full Height

Capacity         500 lbs (227 kg)

Capacity (Overall)

Distributed Capacity (Main Platform)         250 lbs (113 kg)

Distributed Capacity (Extension Deck)         250 lbs (113 kg)

Local Floor Load (With Rated Load)         104 psi (718 kPa)

Overall Floor Load (With Rated Load)         241 psf (1177 kg/ m2)

Maximum # of Persons         2

Tire Type         Solid, N/M

Tire Size         16 x 5 x 12
