2023 SKYJACK
| Work Height | 37' 8" (11.48 m) | |
| Raised Platform Height | 31’ 8” (9.65 m) | |
| Lowered Platform Height | 50” (1.27 m) | |
| Overall Width | 47” (1.19 m) | |
| Overall Length | 91.6” (2.32 m) | |
| Stowed Height (Rails Up) | 94” (2.39 m) | |
| Stowed Height (Rails Down) | 78.5” (1.99 m) | |
| Platform Width (Inside Dimension) | 42” (1.07 m) | |
| Platform Length (Inside Dimension) | 83” (2.11 m) | |
| Extension Deck (Roll Out) | 4’ (1.22 m) | |
| Wheelbase | 69” (1.75 m) | |
| Weight | 5,496 lbs (2,492 kg) | |
| Gradeability | 25% | |
| Turning Radius (Inside) | 28” (0.71 m) | |
| Turning Radius (Outside) | 104” (2.64 m) | |
| Lift Time (With Rated Load) | 50 sec | |
| Lower Time (With Rated Load) | 30 sec | |
| Drive Speed (Stowed) | 2.0 mph (3.2 km/h) | |
| Drive Speed (Raised) | 0.6 mph (1.0 km/h) | |
| Maximum Drive Height | Full Height | |
| Capacity | 700 lbs (318 kg) | |
| Distributed Capacity (Main Platform) | 450 lbs (204 kg) | |
| Distributed Capacity (Extension Deck) | 250 lbs (113 kg) | |
| Local Floor Load (With Rated Load) | 124 psi (856 kPa) | |
| Overall Floor Load (With Rated Load) | 222 psf (1083 kg/ m2) | |
| Maximum # of Persons | 2 | |
| Tire Type | Solid, N/M | |
| Tire Size | 16 x 5 x 12 |
- Status:New
- Vehicle:2023 SKYJACK SJ4732 SCISSOR LIFT
- Location:Wise Honda
- Warranty:Manufacturer's w/ Extended Available
