Work Height | 24’ 6” (7.47 m) | |
Raised Platform Height | 18’ 6” (5.64 m) | |
Lowered Platform Height | 41” (1.04 m) | |
Overall Width | 32” (0.81 m) | |
Overall Length | 71” (1.80 m) | |
Stowed Height (Rails Up) | 84” (2.13 m) | |
Stowed Height (Rails Down) | 79.75” (2.02 m) | |
Platform Width (Inside Dimension) | 26” (0.66 m) | |
Platform Length (Inside Dimension) | 61” (1.55 m) | |
Extension Deck (Roll Out) | 3’ (0.91 m) | |
Ground Clearance (Stowed) | 3.5” (8.9 cm) | |
Ground Clearance (raised) | 0.50” (1.3 cm) | |
Wheelbase | 54” (1.37 m) | |
Weight | 3,255 lbs (1,476 kg) | |
Gradeability | 25% | |
Turning Radius (Inside) | 0 | |
Turning Radius (Outside) | 65” (1.65 m) | |
Lift Time (With Rated Load) | 19 sec | |
Lower Time (With Rated Load) | 25 sec | |
Drive Speed (Stowed) | 2.1 mph (3.4 km/h) | |
Drive Speed (Raised) | 0.7 mph (1.1 km/h) | |
Maximum Drive Height | Full Height | |
Capacity | 500 lbs (227 kg) | |
Distributed Capacity (Main Platform) | 250 lbs (113 kg) | |
Distributed Capacity (Extension Deck) | 250 lbs (113 kg) | |
Local Floor Load (With Rated Load) | 168 psi (1,159 kPa) | |
Overall Floor Load (With Rated Load) | 243 psf (1,188 kg/m2) |
