Overall Width | 8’ 5” (2.56 m) | |
Ground Clearance | 19” (48.3 cm) | |
Turning Radius (Outside) | 153” (3.89 m) | |
Fuel Tank | 35 gal. (132 L) | |
Hydraulic Reservoir | 43.85 gal. (166 L) | |
Maximum Lift Capacity | 10,000 lbs (4,535 kg) | |
Maximum Lift Height | 56’ 3” (17.14 m) | |
Maximum Forward Reach | 42’ 6” (12.85 m) | |
Rated Lift Capacity @ Maximum Height | 4,000 lbs (1,814 kg) | |
Rated Lift Capacity @ Maximum Reach | 400 lbs (181 kg) | |
Rated Lift Capacity @ Maximum Height (on outriggers) | 6,000 lbs (2,722 kg) | |
Rated Lift Capacity @ Maximum Reach (on outriggers) | 3,000 lbs (1,361 kg) | |
O/A Length - Less Forks | 22’ 2” (6.75 m) | |
Overall Height - Stowed | 8’ 1” (2.47 m) | |
Operating Weight | 33,336 lbs (15,121 kg) | |
Engine | 74hp / 287 lb-ft Deutz TCD 3.6L T4F | |
Max Travel Speed - Forward | 15 mph (24 km/h) | |
Transmission | Dana Powershift, 3 Speeds F/R | |
Axles | Dana | |
Steering | 3 mode (Front Wheel, 4 Wheel, Crab) | |
Tires | Foam Filled 14 x 24 16PR Grip Lug | |
Drawbar Pull | 20,000 lbs |
